Phase II Horizontal - Vertical 5C Collet Indexers

Brand:

(No reviews yet) Write a Review


Phase II Horizontal - Vertical 5C Collet Indexers

Features:

  • Spindle is manufactured with tapered seat in body frame
  • Lever operated collet collet closer with 100:1 leverage ratio
  • Front mounted ratchet control for rapid indexing
  • Furnished with a 24 space indexing plate
  • Dividing spindle concentricity: 0.0002"
  • Cylindrical center bore (per 1"): 0.0008"
  • Spindle centerline parallelism: 0.0008"
  • Base to face squareness: 0.0008"
  • Center slot to dividing spindle concentricity: 0.0008"
  • Lateral offset of center slot of dividing spindle: 0.0008"
