Kent Universal Mills
- Main castings are made of Meehanite cast iron to insure high tensile strength and rigidity
- Hardened and ground slideways assure accuracy and wear resistance
- Main spindles and intermediate shafts are made of Nickel Chrome alloy steel and hardened and ground
- +/-45 degree swivel table
- Centralized lubrication system
- Heavy duty and versatile manual turret mill
- X axis ACME screw with feed gear box, Manual Y axis, Z axis rapid motor
- No. KUM-2500UM 10 HP horizontal spindle motor,12 speed ranges(40~1800RPM),13.7”x 72.8” hardened and ground table top
- Saddle and knee with hardened and ground square (box) ways
- Table swivels ± 45 degrees left & right
- Meehanite® casting body GC-45/DIN-40
- X,Y and Z axis are variable speed with inverter by gear-box
- Rapid traverse on X,Y and Z axis
- All gears and shafts are hardened and ground
- Extra wide square cross and knee ways and dovetail longitudinal ways for enhanced rigidity
Standard Accessories
- Coolant
- Longitudinal Gear Box Feed
- Table Elevating Motor
- Tools & Tool Box
- Leveling Blocks
- Leveling Bolts
Optional Accessories
- Vertical Milling Head
- Horizontal & Vertical Rotary table
- Dividing Head
- Clamping Kit
