Fein 4" x 4" Magnetic Base Drill
JHM 4 x 4 - Magnetic Base Drill up to 4 in (101 mm)
With four-speed, 4 in diameter capacity with MT 3
- 4-speed gear box powering through small and large holes
- Versatile, MT 3 capable
- Smart Magnet TM circuitry for safe drilling on marginal surfaces
- Chip guard
- Gravity-fed, external coolant
- Easy to use control panel
- Concealed motor wiring
- Pilot pin coolant feed
- Dovetail feed guides
Includes:
- 1 case
- 1 coolant tank
- 1 safety strap
- 4 centering pins
- 1 Allen key 5 mm
- 1 touch guard
- 1 Carrying handle
Technical Data:
| HSS core bit max. dia. | 4 in |
| Core drill, max. drilling depth | 3 in |
| Twist drill max. dia. | 1 1/4 mm |
| Power consumption | 1,400 Watts |
| 1st gear | 150 rpm |
| 2nd gear | 220 rpm |
| 3rd gear | 290 rpm |
| 4th gear | 450 rpm |
| 1st gear | 100 rpm |
| 2nd gear | 150 rpm |
| 3rd gear | 200 rpm |
| 4th gear | 310 rpm |
| Core bit holder | 3/4 in Weldon |
| Stroke | 8 7/16 in |
| Magnetic holding force | 4,833 lbs |
| Magnetic base sizes | 7 1/2 x 4 in |
| Cable with plug | 13 ft |
| Weight according to EPTA | 73 lbs. |
