Eagle Rock Air Collet Fixture  A1-212-5CS

For use with standard Hardinge® 5C Collets.

Designed especially for high production applications. Their light weight and compact size permits the use of several units on indexing tables for custom applications or used individually for fast chucking of parts on milling machines and drill presses.

Air operation is double acting for “Power” opening and closing of the collet. The collet is locked into position for positive depth location of work. These units operate efficiently and effectively on air pressure up to 150 PSI with upward clamping pressure exceeding 7.5 times line pressure. All bearings and moving parts are hardened and precision ground for accuracy and long life.

Specifications

Collet Type 5CS Capacity 2" Base Dia. 5-1/2" Height 4-3/4"
