Dyer Classic Direct Reading Mini Wall Thickness Gages

Maximum Measuring Accuracy
Linear Accuracy at 0.100" Travel
± 0.0005" (± 0.010 mm)
Full Range ±0.001” (± 0.020 mm)
Repeatability ≤ 0.0005"/0.010 mm

Fast, accurate, repeatable measurements.

• Large easy to read graduations in 0.0005"/0.01 mm.
• Rack gear movement increases accuracy and repeatability. Oil and corrosion resistant.
• Fine steel alloyed arms, special machined case, light-weight, easy-to-use, 24-7 durable, shop-rugged gage.
• Spring-loaded arms, eliminate operator “hand-touch” variances.
• Gages reach over flanges, around curved surfaces, and reach hard to get to measurements. Special arm designs available quickly.
