Electro Arc Carbide Disintegrator Model 2SAC

The Model 2SAC is a complete table top disintegration work center with the work support, head support and coolant system needed for an efficient disintegration process. The good-sized table makes it popular with manufacturers of small castings and machinery such as pumps and motor housings.


Standard Features:

• 813MM (32") wide x 813MM (32") deep cast iron work top with precision-ground surface and five T-slots to secure your work piece.
• Steel base cabinet of heavy, reinforced frame construction that holds work top 813MM (32") above floor on four heavy-duty rubber wheel casters.
• Disintegration head support system consisting of a 1270MM (50") high by 70MM (2-3/4") diameter column and a 762MM (30") long by 57MM (2-1/4") diameter cross arm for solid support. The cross arm rotates 360° around the column, a manual compression lock holds it in position

Additional Features:

• Compact durable head with 305MM (12") uninterrupted quill travel that makes and breaks an arc 120 times per second. It has a push button remote start, auto depth stop and limit switch. Any conductive material can be used as an electrode but molybdenum tubes are recommended.
• 305MM (12") lift rack
• Current Indicator for precise current control
• Lighted push buttons plus emergency stop button
• External fuses
• Built-in coolant system, with a 90 PSI pump, coolant tank plus drainage channels in the worktop, provides optimal control and recycling of coolant.
• Precision ground and chromed quill assemblies
• Rack and pinion movement
• Power supply is a controlled rectified DC cutting power in eleven heat selections. Disintegrates high speed and carbide materials fast under servo control. Input AC power input available in 208, 240, 383, 440 or 575
