Knu-Vise Vertical Hold Down Clamp 6.19" Throat Depth - CAV-1200

Brand:

(No reviews yet) Write a Review
SKU:
CAV-1200
Base:
Flanged
Holding Capacity:
1200 lbs.
Max. Clamping Thickness:
3.13"


Knu-Vise Vertical Hold Down Clamp 6.19" Throat Depth - CAV-1200

The Hold-Down action is the most common type of toggle clamp. They are available with handle that are either vertical or horizontal when the clamp is closed. They are used to apply a downward clamping force.

  • Weight: 6.7 lbs 3.04 kg
  • Holding Capacity: 1200 lbs 5338 N
  • Holding Capacity 3.13 in Front of Base: 2200 lbs 9786 N
  • Maximum Clamping Thickness: 3.13 in 79.4 mm
  • Throat Depth: 6.19 in 157.2 mm
  • Cam action allows for variations of up to 7/16in in the material being clamped without spindle adjustment
  • Included 1:Spindle Assembly (N-470020):

For More Knu-Vise Hold Down Clamps Click Here

Knu-Vise Vertical Hold Down Clamp 6.19" Throat Depth
