Birmingham 14" x 40" Geared Head Precision Engine Lathes

Brand:

Call for Pricing

(No reviews yet) Write a Review

Birmingham

Birmingham 14" x 40" Geared Head Precision Engine Lathes

YCL-1440GH


Complete With:

  • 6" 3-Jaw chuck
  • 8" 4-Jaw chuck
  • Follow rest
  • Full length splash guard
  • Steady rest
  • 10" face plate
  • Chip pan
  • Coolant system
  • D1-back plate
  • Work light

Features:

  • Hardened and ground bedways and splinned shafts in headstock
  • 16 speeds all geared headstock from 45 to 1800 ppm
  • Foot brake giving rapid braking and built in coolant system.
  • Emergency stop button equipped on front of head stock.
  • Jog button for easy engagement and inclining spindle.
  • Open type chip pan easily removes chips.
  • 3HP 2 speed, 220V
  • Extra safety switch shuts down machine entirely for changing belt or gear for threading cutting.
  • Built in full size splash guard and lamp for worker's convenience.

lowest cost lathe best price lathe lathe cheap engine lathe lowest cost economical lathe
Best prices lathe lowest priced lathe cheapest lathe low cost lathe lowest cost engine lathe precision lathe cheap
Specifications:

Capacities
Max. swing over bed 14"
Distance between centers 40"
Max. swing over cross slide 8 5/8"
Effective length in gap 6 1/4"
Width of bed 8 1/8"
Headstock
Spindle nose (spindle mount) D1-4
Diam. of spindle thru bore 1 1/2"
Spindle taper (with sleeve) M.T. 5 (M.T. 3)
Spindle speeds 45-1800rpm, 16 steps- 45,70, 90, 108,
140, 165, 215, 255, 330, 385, 510, 585,
770, 900, 1170, 1800, rpm
(1 phase 90 - 1800 RPM)
Feeds & Threads
Longitudinal Feeds 0.0012-0.0294 inch/ REV. (40 kinds)
Cross feeds 0.0003-0.01 inch Rev. (40 kinds)
Inch threads 4-112 tpi (40 kinds)
Metric threads 0.45-7.5 mm (22 kinds)
Diam. of long leadscrew 7/8"
Pitch threads of long leadscrew 8 tpi
Carriage
Max. travel of cross slide 7"
Max. travel of compound slide 4"
Max. tool size 5/8" x 5/8"
Tailstock
Diam. of tailstock quill 2 3/4"
Taper of tailstock quill center M.T. 3
Max. travel of tailstock quill 4 3/4"
Motors
Power of main motor 3HP, 220V 2 speed
Power of coolant pump 1/8 HP, 220V, 1,3 PH
Overall Dim. (L x W x H) 72" x 31" x 49"
Net weight 2000 lbs.
