Baileigh 19.685' Table Size CNC Plasma Tube Profiler - PTP-1120

The PTP-1120 plasma tube profiling machine is the economical choice in notching and profiling tube and pipe with plasma. This CNC pipe-cutting solution features a compact footprint of only 2-feet wide by 22-feet long and can rapidly finish 20-foot material. the PTP-1120 also improves pipe fabrication productivity and quality by utilizing easy set-up, programming and cutting.

The controller provides effective cutting on X-Y axis and the included software allows the operator to take the design-software-generated G code and take it directly to the controller. The movement of the axis are controlled by stepper motors, providing smooth carriage motion. A pneumatic chuck opens and closes the vice so that material can be easily loaded, positioned for cutting and unloaded.

The PTP-1120 pipe cutter machine uses a variable-angle, manual height control for plasma torches. It is capable of cutting and profiling pipe with an outside diameter range of 2" 11.5". The PTP-1120 is perfect for the shop that needs to quickly and efficiently make a wide range of cuts. These cuts include straight, miter, saddle, center offset, multiple intersection and gusset slots. The Plasma Tube Profiling Machine also cuts round, rectangular and overlapping pipe holes.

• 2 axis design allows for many unique applications
• Perfect for notching large tube
• CNC controlled
• Includes software
• 2"–11.5" (50 – 300mm) OD capacity
• 220V single phase
• Plasma system sold separately (based on capacity)

For More Baileigh CNC Plasma Tube Profilers Click Here

Part Number: PTP-1120

Stock Number: 1013937

UPC: 731325446593
