Sine System- Compound Sine Plates - 77-074-3

Brand:

Sine System- Compound Sine Plates - 77-074-3
Sine System- Compound Sine Plates - 77-074-3
(No reviews yet) Write a Review
SKU:
77-074-3
Center Distance of Rolls:
5" & 15"/.0003"
Dimensions:
6 x 18 x 5-3/8"
Sine System:
2
Sine System- Compound Sine Plates - 77-074-3
Sine System- Compound Sine Plates - 77-074-3
  • Made in U.S.A.
  • Made of quality steel, hardened to 58-62 Rc.
  • 0 - 60° capacity.
  • Minute angle step .200" built into the gage block roll. Eliminates steps in base plate.
  • Two hardened and ground side rails and two locking straps included.
  • Locking strap always remains below the top surface.
  • Large hinge pins for extra strength.
  • Tapped holes in top plate 6 x 6" or smaller 1/4-20. Larger models have 3/8-16 tapped holes.
Compound Sine Plate
Add to Cart
Item NumberDescriptionCenter Distance of RollsDimensionsSine SystemPriceQuantity
77-074-3Compound Sine Plate5" & 15"/.0003"6 x 18 x 5-3/8"2$10,995.00
Add to Cart
