New 100mm (4") size.
High clamping force (up to 40 kN) exactly where it is needed, by incorporating the tension spindle directly below the work piece support.
No flare out of jaws under tension, no distortion on machine table.
The special design and a clamping depth of just 8mm permits obstruction free machining on 5 sides.
Positive clamping with embossing jaws.
Any desired clamping width, limited only by the size of the machine table. The two clamping jaws, one fixed and one moving, can be positioned at any desired distance from each other.
Clamps blank work pieces, machined work pieces, round and irregularly formed work pieces.
VB 5AX100-L Schenke Clamping System can be mounted on T-slot or location grid machine tables or any custom fixture.
Made in Germany.
