Product features

• The MarSurf PS1 lives up to its claim of "Absolute mobility" in all manner of ways, providing:
• Mains-independent operation Over 500 measurements without having to recharge the instrument
• An all-in-one solution that is no larger than a digital camera. Small and lightweight (400 g / 0.88 lbs)
• Instrument flexibility: The standard range of functions is sufficient for this all-purpose smart little instrument to perform your measuring tasks.
• All the measuring positions you need: Can be used horizontally, vertically, upside down or in any other position required by the component.
• 25 parameters: Offer the same range of functions as a laboratory instrument.
• Error-free operation thanks to an integrated roughness standard.
• Automatic cutoff selection (patented) so that even non-specialists are ensured correct measuring results.
• Simple operation The brief guide in pocket diary format reflects how simple the PS1 is to use. You quickly get to grips with the essential features, enabling you to complete your measuring tasks with excellent results.



  		6910214 - PS1-Set/USA MarSurf
  Measuring principle		stylus method
  Probe		Inductive skidded probe
  Measuring units		metric/inches
  Measuring range mm		350 µm, 180 µm, 90 µm (automatic switching)
  Profile resolution		8 nm
  Filter according to ISO/JIS		Phase-correct profile filter as per DIN EN ISO 11562, Special filter according to DIN EN ISO 13565-1, ls-Filter according to DIN EN ISO 3274 (disengageable)
  Short stroke under ISO/JIS		selectable
  Traversing length according ISO 12085 (MOTIF)		1 mm, 2 mm, 4 mm, 8 mm, 12 mm, 16 mm
  Evaluation lenth In according to ISO/JIS		1.25 mm, 4.0 mm, 12.5 mm
  Number n of sampling length according to ISO/JIS		selectable: 1 to 5
  Stylus		5 µm
  Measuring force (N)		approx. 0.7 mN
  Calibration function		dynamic
  Storage capacity		max. 15 profiles, max. 20000 results
  Other		Locking/password protection, date/time
  Rechargeable batteries		lithium-ion battery
  Wide range power supply		100 to 264 V
  Dimensions in mm		140 x 50 x 70
