Fowler Tool Master Lite Tool Presetter - 54-188-777

Brand:

(No reviews yet) Write a Review
SKU:
54-188-777


The Fowler Tool Presetter stand was designed for maximum productivity with ultimate user-friendliness.
Tool Master Lite is a simple and user friendly presetter.

Features:

  • User friendly
  • Swiss quality
  • Reduces setup times
  • Measures all types of tooling
  • No connection to power or compressed air needed
  • Needle bearing tool pot can be used with various adaptors, contact Fowler's technical department for details
  • Easy to use digital display for each axis
  • High concentricity needle bearing tool pot
  • Maximum measuring repeatability
  • Smooth ball bearing guides

Specifications:

Measuring Range X axis: 9.8" / 250mm
Z axis: 11.8" / 300mm
Accuracy (X and Z) .0008" / .02mm
Fine Adjustment X axis
Tool Mounting Needle bearing SK 50 - standard
Measuring Method Contact
Dimensions 420 x 150 x 590mm
Weight 23 kg (51 lbs.)
Power Battery (AA type)
Fowler Tool Master Lite Tool Presetter
