The Mahr Federal CX2 24"/600mm electronic height gage is the perfect partner for use on the shop floor or inspection areas. Obtain your measurement results without complicated procedures; simple, fast and accurate. The CX2 is by far the best value in its category. Compare for yourself.
Extremely accurate capacitive incremental measuring system.
Dynamic probing system enables high repeatability.
Motorized measuring carriage minimizes operator influence.
Resolution to 0.00005"/0.001mm.
Absolute and Relative modes.
Easy to read LCD display.
Quick and easy icon labeled operating keys.
RS232 data output/ Wireless available

Specifications:

Measuring Range: 24"/600mm

Application Range: 36.81"/935mm

Resolution: 0.0001"/0,00005"/0.01/0.001mm

Measuring error* (U95): (5+L.300)µm, L in mm

Repeatability* : 2 (plane) 3 (bore) µm

Perpendicularity error( electrically adjusted):?15µm

Operating time between charges: up to 100h

Measuring Force: 1.0±0.3 N

Measuring System: Incremental Capacitive

Total Height: 38.78"/985mm

Base Area : 9.45" x 9.84"/240mm 250mm

Weight: 35.27 lbs./16kg

*Surface Plate GK 0 according to DIN 876
with Probe K10/50
