Mitutoyo "Quick-Set" Dial Test Indicator Set, Horizontal Type, 0.8mm Range - 513-404-10T
- Drastically enhanced durability, sensitivity and visibility.
- Glare-free flat crystal face allows easy reading of graduations.
- Preventing dust and oil from penetrating to the dial face. The O-ring seal on the bezel has the effect of providing smooth rotation and prevents dust and oil from penetrating through to the dial face.
- Multi-layer coatings on the Crystal.
- Hard and non-glare coatings on the crystal inhibit scratches, contamination and glare on the surface.
- Jewelled bearings and precision gears and pinions give you smooth, accurate movement and quick response.
Features:
- Anti-magnetic
- Jeweled bearings
- No-clutch structure
- Water and dust resistant
- Glare-free crystal with scratch-resistant coating
- Metric dial faces in yellow
- The most direct gear train design ever applied to Test Indicators means—higher level of sensitivity, reliability, repeatability and accuracy throughout tool life.
Specifications:
| Range | 0.8 mm |
| Graduation | 0.01 mm |
| Scale | 0-40-0 |
| fe | 8 µm |
| fu | 3 µm |
| fges | 13 µm |
| Measuring force | ≤ 0,3 N |
| Carbide stylus tip ø2 mm No. | 103006 |
| Mass | 42 g |
| Contact point | Thread M 1,7 x 0,35 |
| Delivered | In box with clamping shaft ø8 mm |
| Jeweled bearing | Yes |
| Anti-magnet | Yes |
| Inch-Metric | Metric |
| Functions | Full set |
