Ridgid Model 700 Power Drive Model 41935
Features:
- Heavy-duty hand-held power drive.
- Features reversible 115V or 230V universal motor.
- Capacity 1/8"-2" (3mm-50mm) pipe, 1/4"-1" bolt with OO-RB die heads. Designed for RIDGID No. 12-R die heads. Other RIDGID die heads (OO-R, OO-RB, 11-R) using adapters, threading 2 1/2" through 6" (62mm-150mm) with 141/161 geared threaders. Also used with 258/258XL pipe cutters. Die heads not included, see page 4.5.
- Approved by CSA to CSA and UL standards (115V only).
Technical Specifications:
| Motor: | Universal, 1/2 HP, 115V or 230V 50/60 Hz. |
| Switch: | Double-throw reversible. |
| Gear Head: | All-spur gear reduction. Spring-loaded adapter pawl. Hardened steel spindle gear. |
| Body: | Cast aluminum. |
| Spindle Speed: | 26-30 RPM (no load). |
| Capacity: | 1/8"-2" Pipe (3mm-50mm). 1/4"-1" (6mm-25mm) Bolt (using 00-RB). |
| Weight: | 25 lbs. (11 kg) Power Drive only. |
| Length: | 28 1/4" (71.7 cm). |
RIDGID POWER THREADER 115V
