Mitee-Bite 6mm Press Fit Pin - 38730

Brand:

(No reviews yet) Write a Review
SKU:
38730
A:
13mm
B:
7mm
C:
7.3mm
D:
5.8mm
E:
M3x.5
F(+/-) .000/.001″(.000/.025mm):
.250"
G*:
.219″


Mitee-Bite 6mm Press Fit Pin - 38730


Pins are intended for press fit or close tolerance removable slide fit applications. Install in a precision bore or a bushing with the center threaded for the Tapered screw. If precise location is not necessary, pin can be used on top of fixture plate. Mitee-Bite provides a simple tool to make Installation and Removal (I/R) of the XYZ Pins quick and easy. Note: If recessing pin into fixture beyond slits be sure to provide clearance for expanding segments.

*G – Minimum diameter pin can be machined or turned down to
** Set includes screws (2) SHCS



See all Mitee-Bite Press Fit Pins

6mm Press Fit Pin
