JET Geared Head Mill/Drill JMD-45GHPF with Power Downfeed & Newall DP500 2-Axis DRO - 351160
Geared Head Square Column Mill/Drill
The heavy-duty JMD-45GHPF Square Column Geared Head Mill Drill with power downfeed capability is engineered to deliver the rigidity needed to perform a variety of precision drilling applications in high intensity environments.
Features:
- Heavy-duty design allows for a variety of precision drilling applications
- Full power to the cutting tools through 6 speed geared head
- Square column with dovetail ways
- CSA/CUS: Following strict guidelines and electrical requirements, this JET Mill Drill is CSA/CUS certified
- Spindle guard
- Work Lamp
- Calibrated fine down feed built in
- Easy to read internal depth gauge
- Head tilts left & right 90º
- Rapid spindle speed changes through quick-select gear shift levers
- Forward/reverse switch
- Power Downfeed standard
- Milling table allows for movement
- R8 spindle allows use of all mill tooling
Specifications:
| Item Number | 351160 |
| Model | JMD-45GHPF |
| DIGITAL READOUT | DP500 2-AXIS DRO |
| DRILLING CAPACITY | 1-1/2" |
| FACE MILL CAPACITY | 4" |
| END MILL CAPACITY | 3/4" |
| SWING | 19-11/16" |
| MAX DISTANCE SPINDLE TO TABLE | 18-1/8" |
| SPINDLE TAPER (IN. X TPI) | R8 |
| SPINDLE TRAVEL | 5" |
| QUILL DIAMETER | 3" |
| COLUMN DIAMETER | 7-7/8" x 7-5/8" SQUARE |
| NUMBER OF SPINDLE SPEEDS | 6 |
| RANGE OF SPINDLE SPEEDS (RPM) | 65-1550 |
| TABLE SIZE (L X W) | 9-1/2" x 32-1/4" |
| TABLE LONGITUDINAL TRAVEL | 20-1/2" |
| T-SLOTS NUMBER AND SIZE | 4 & 5/8" |
| BASE DIMENSIONS | 26-11/16" x 15-15/16" |
| OVERALL DIMENSIONS (L X W X H) | 29" x 36" x 50" |
| MOTOR (HP) | 1-1/2HP, 115/230V, 1PH |
| WEIGHT | 820 lbs. |
