Mitutoyo Screw Thread Micrometer, 0-1" with Anvil Set (126-800) - 126-901
Screw Thread Micrometer - Series 126 - Interchangeable Anvil-Spindle Tip Type
Features:
- IP65 water/dust protection (Series 326)
- 60 degree or 55 degree V-anvil and conical spindle(interchangeable) are optional,which are made of high-grade steel,hardened and precision ground
- With Ratchet Stop for constant force
- With SPC output (Series 326)
- With a standard bar except 0-25mm / 0-1 in model
- Suplied in fitted plastic case
Technical Data:
- Resolution*: 0.001mm or .00005"/0.001mm
- Graduation**: 0.01mm or .001"
- Spindle feed error: 3µm/.00012”
- Display*: LCD
- Battery*: SR44 (1 pc.), 938882
- Battery life*: Approx. 1.2 years under normal use
- Dust/Water protection level*: IP65
* Digital models
** Analog models
Anvil Set (126-800) Contains:
| Item Number | Threads per Inch | Pitch (mm) |
| 126-801 | 64-48 (M1) | 0.4 - 0.5 |
| 126-802 | 44-28 (M2) | 0.6 - 0.9 |
| 126-803 | 24-14 (M3) | 1 - 1.75 |
| 126-804 | 13-9 (M4) | 2 - 3 |
| 126-805 | 8-5 (M5) | 3.5 - 5 |
| 126-806 | 4.5 - 3.5 (M6) | 5.5 - 7 |
See all Mitutoyo Screw Thread Micrometers, Series 326, 126 - Interchangeable Anvil-Spindle Tip Type
Screw Thread Micrometer with Anvil Set (126-800)
